Application:

MKL-A tricyclic medium speed micro powder mill of kaolin, limestone, calcite, marble, talc, barite, gypsum, dolomite, bentonite, mica, pyrophyllite, sepiolite, diatomite, graphite, alunite, fluorite, potassium feldspar, phosphate rock, pigments, such as humidity less than 6%, mohs hardness is not more than hundreds of level 6 kinds of inflammable and explosive materials are ultra-fine powder processing. Finished product size 325-2500 mesh (0.044-0.005mm).

Working principle of the Superfine vertical mill :

The motor of the main machine drives the milling disc to rotate through the reducer. At the same time, the airflow generated by the high-pressure fan enters the main machine from the air inlet. The material is fed into the main machine of the vertical mill through the feeding screw and falls into the center of the milling disc. , When passing through the roller table area on the grinding disc, the large pieces of materials are directly crushed under the pressure of the grinding rollers, and the small particles of materials are pressed and then subjected to inter-particle grinding to further pulverize until they become powder. The powdered material continues to move to the edge of the grinding disc until it is taken away by the strong airflow from the air inlet. When the material in the airflow passes through the upper powder separator, under the action of the centrifugal force generated by the high-speed rotating impeller, the coarse particles fall into the grinding disc again. After grinding, the qualified powder passes through the powder selection system with the airflow and is collected by the dust collector, which is the finished product.

Advantages of the Vertical Roller Mill:

1. Low operating cost

The grinding wheel and the grinding disc lining are made of special alloy wear-resistant materials, the wearing parts have a long service life and the maintenance cost is extremely low. The convex surface of the grinding wheel and the concave surface of the grinding disc are specially designed to form a stable and effective material bed. The vibration of the whole machine is small, and the powder formation rate is high. Compared with similar domestic products, the production capacity is 20% higher and the energy consumption of equipment such as ball mills is reduced by 40%.

2. The product has high added value

With the multi-head powder separator structure, the fineness of the finished product can be achieved within D97 5-45 microns. The high-efficiency precision rotor adopts PLC frequency conversion control system, and adjusts the powder selection mode according to the different requirements of customers, which can realize the production of 20%-70% products with 2 micron content. After classification, the ultrafine powder produced by CLUM series ultrafine vertical mill has the advantages of narrow particle size distribution, controllable 2 micron content, and good powder particle size, which greatly improves the added value and application fields of the finished product.

3. The system is safe and reliable

Adopt PLC/DCS automatic control method of grinding roller pressure control, the grinding pressure is accurate, without manual operation. The contact between the grinding roller sleeve and the grinding disc liner adopts electronic limit and mechanical limit protection to avoid severe vibration and destructive impact. The gearbox box and lubrication system adopt multiple detection and protection devices. The grinding roller lubrication adopts an independent lubrication station. A single grinding roller lubrication circuit adopts double pumps. It will cause oil leakage due to excessive oil storage. The CLUM host equipped with multiple intelligent protection devices can realize continuous operation without stopping, and the operation process is efficient, safe and stable.

4. Green and environmental protection

Since the grinding roller and the grinding disc are not in direct contact during work, there is no metal impact sound during the work of the ball mill, and the vibration of the equipment is small during operation, and the noise is 20-25 decibels lower than that of the ball mill, which will not cause harm to the human body. The equipment is sealed as a whole, the system works under negative pressure, and the finished product is directly sent to the large finished product warehouse by the gas conveying equipment. There is no dust spillover, the production environment is tidy, and the national environmental protection requirements are met.

Complete set of the Three-ring micro-grinding machine

First class service and professional technicians make our company the pioneer in the same field and provide more high quality Feldspar Bauxite Powder Grinding Plant with Capacity 40tph for our customers. Technological innovation has always been our advantage, and in the future we will strengthen and enhance it even more to build our core competitiveness. We firmly believe that product quality is a comprehensive reflection of science and technology, staff quality and management level.
